XAG APC1 Auto Pilot Agricultural machinery self-driving instrument (no tablet included)

Product image 1
Product image 2
Product image 3
Product image 4

XAG APC1 Auto Pilot Agricultural machinery self-driving instrument (no tablet included)


Overview

Introducing the

XAG APC1 Auto Pilot Console

Navigate with Precision

Autonomous, precise operation | Cost-effective performance | Easy to operate

    XAG AutoPilot Console empowers small-to-large agricultural equipment with capability to conduct high-precision farming operations. An automated steering system with access to signals from RTK Base Station, simply connected to mobile app and primed by easy tabs. From tillage, seeding, crop management to harvest, APC1 can ease you from long hours of concentration.

    Autonomous, precise operation
    RTK navigation technology enables agricultural vehicles to operate automatically in 2.5 cm accuracy.


    Cost-effective Performance
    Auto driving on designated straight path that avoids skip and overlap to save time and reduce cost


    Easy to Operate
    Select target area and pre-program route on mobile app to enable hands-free operation with ease

    One System for Multiple Machines, Never been Easier

    XAG AutoPilot Console can be flexibly transferred between various types of agricultural machinery. Quick assemble within 20 minutes that turns your tractor, sprayer or rice transplanter into a smart, automated machine.

    Want to know more about The XAG APC1 AutoPilot Console?

    Click the "More Info" tab above







    More Info



    Specifications

    XAG APC1 AutoPilot Console Specs

    Console

    Steering Control

    Automatic

    On-Board Processor Model

    MT6873

    On-Board Computer RAM

    6 GB

    On-Board Computer Hard Drive

    64 GB

    On-Board Computer OS and Software Version

    Android 7.0

    On-Board Computer Display Size and Resolution

    6.5 inches, 2400x1080

    On-Board Computer Port

    Type-C

    On-Board Computer Data I/O Protocol

    Wi-Fi protocol

    Satellite Receiver Type and Bands

    Multi-band navigational receiver,

    BDS B1/B2 GPS L1/L2 GLONASS L1/L2 Galileo E1/E5b*

    Satellite Receiver Mainboard Firmware Version

    R2.00Build20095

    Satellite Receiver Channels

    432 channels

    Satellite Receiver Port

    UART

    Satellite Receiver Differential System

    RTCMV2, RTCMV3

    Satellite Receiver Update Rate

    5 Hz

    Satellite Receiver Antenna

    Helix antenna

    Steering Controller Mainboard Firmware Version

    1.0.0.8

    Hydraulic Valve/Motor Model

    SW-ED10

    Fixed Base Station Signal Coverage

    30 km

    Radio Transmitter Frequency

    2400 MHz

    Power of Fixed Base Station Radio Transmitter

    6 W

    Integration Components

    Satellite antennas, receiver & radio station;

    electric steering wheel & controller

    Dimensions

    220*616*267 mm

    Positioning Accuracy

    Horizontal: 1 cm+1 ppm

    Vertical: 1.5 cm+1 ppm

    Operating Accuracy

    ±2.5 cm

    Power Input

    DC12 V ~ 24 V

    Satellite System

    Beidou/GPS/GLONASS

    Communications Protocol

    Wi-Fi, Cloud connection

    Wi-Fi Frequency

    2.4/5.8 GHz

    Break-Point Endurance

    10 min

    Operating Temperature

    -20℃ ~50℃

    Storage Temperature

    -40℃ ~70℃

    Radio Transmit Power of AutoPilot Console

    3 W

    Operating Speed Range of Agricultural Machinery

    0.3 km/h~13 km/h

    Motor

    Dimensions

    220*210*87 mm

    Steering Wheel Diameter

    410 mm

    Rated Voltage

    12 V

    Maximum Voltage

    28 V

    Isolation Voltage

    500 VDC

    Torque

    Rated: 10 NM

    Maximum: 20 NM
